AB-50PP-1/AB-50J

PP Drinking Straw Extruder

The AB-50J PP straw extruder is designed for continuous production of single-color plastic drinking straws. The machine combines a 50 mm extrusion unit, water cooling, haul-off and cutting systems, with frequency-controlled operation for straw diameters from 2 to 13 mm and production speeds of approximately 300–1000 pcs/min.
Output (kg/h):
Contact expert Go back
Product Overview

Choose the AB-50J for standard single-color PP straw production with moderate output requirements. For higher throughput or PP and PLA material flexibility, compare the AB65J 65 mm straw extruder.

Machine Configuration

  • 50 mm extrusion unit
  • Heating and temperature control
  • Water cooling tank
  • Haul-off unit
  • Cutting system
  • Collection section

Suitable Products

  • Single-color PP drinking straws
  • Straight-cut straws
  • Bevel-cut straws
  • Small- and medium-diameter straws

Standard vs Optional Equipment

  • Dryer
  • Vacuum loader
  • Chiller
  • Air compressor
  • Additional molds
Technical Specifications

AB-50PP-1/AB-50J

Model

AB-50J / AB-50PP-1

Power supply

Main Screw motor

380V, 3 Phase, 50Hz,15Kw, frequency inverter

Heater

15Kw (5Set, 2sets for mold, Others 3sets)

Main motor

380V, 3 Phase, 0.75Kw, speed adjust by frequency inverter

Cutter motor

380V, 3 Phase, 0.75Kw, Speed adjust by frequency inverter

Cooling

Water cooling 1 set

Total Power

23 Kw

Temperature controller

5 Sets

Straw specification

Straw material

PP

Diameter

Φ2-Φ13mm

Length tolerance

0.1-1mm

Working Speed

300-1000 pcs/min

Color

1

Cut angle

90°/60°/45°

Machine Dimension (L×W×H)

8m×1m×1.7m

Machine weight

1.5 Ton
