AB150

Artistic Flexible Straw Making Machine

The AB150 artistic flexible straw making machine converts straight drinking straws into decorative multi-tooth flexible straws. It supports 5.8 mm and 7.8 mm inner diameters, straw lengths from 230 to 330 mm, and production speeds of 100–150 pcs/min. Except for manually loading straight straws into the hopper, feeding, forming, counting and finished-product discharge are completed automatically.

Production Capacity：

100-150 pcs/min

Contact expert

Go back

Product Overview

Choose the AB150 when the finished product requires a long decorative flexible section with approximately 53–58 teeth. For standard short flexible straws or higher output, compare the AB-300WG and AB-900W/G bending machine models.

Running smoothly , stepless adjustable.
Automatic counting. Alarm when the pre-set value is reached, which is convenient for packing.
Automatic stop when fault.

Technical Specifications

Specifications

Type		AB150-5.8mm	AB150-7.8mm
Driving Motor		1.5kw control by frequency converter
Capacity		100~150pcs/min	100~150pcs/min
Specifications of The Drinking Straws	Inner diameter	5.8mm	7.8mm
	Lenght	230~330mm	230~330mm
	Thickness	0.15~0.19mm	0.15~0.19mm
	Teeth	58	53
Machine Dimension (L×W×H)		1900×1800×1600	1900×1800×1600
Machine Weight		1200kg	1200kgs

AB150Configuration List of the machine

Number	Category	Name	Type	Quantity	Remark
1	Appliance Components	Frequency converter	0.75KW	1set	Delta
1	Appliance Components	Motor	0.75KW	1set	Siemens
2		Bearing			NSK

Note : For our continuous development we reserve the right to alter and improve above technical specifications without prior notice.We hope that this proposal will meet your requirements and are very much looking forward to hearing favorable news from you at your earliest convenience.
