AB65J

Drinking Straw Extruder

The AB65J drinking straw extruder combines extrusion, cooling, hauling and cutting for continuous production of PP and PLA drinking straws. With a 65 mm extrusion system, adjustable cooling tank and frequency-controlled drive, it supports output of 60–65 kg/h and production speeds from 400 to 1800 pcs/min, depending on straw size and material settings.

Choose the AB65J for standard PP or PLA straw production with frequency-controlled operation. Choose the AB-65QS full servo model when higher control precision, broader material compatibility or servo synchronization is required.

Output (kg/h)：
Contact expert
Go back
Product Overview

The new extrusion production line developed by the PLA environmental material production center is designed and manufactured according to the material characteristics of PLA material and has the advantages of extruded material plasticization, accurate temperature control, and high energy saving.

Equipment Configuration

  • Extrusion unit
  • Cooling tank
  • Haul-off unit
  • Cutting unit
  • Collection system
  • Electrical control system

Suitable Applications

  • Standard PP drinking straws
  • PLA drinking straws
  • Straight-cut straws
  • Bevel-cut straws
  • Single-color straws

Buyer Selection Factors

  • Material
  • Straw diameter
  • Straw length
  • Wall thickness
  • Number of colors
  • Target output
  • Local voltage
Technical Specifications

Specifications

Main Extruder Motor Host 30 kW, Frequency Controlled
Traction Cutting Device 0. 75kw×2
Production Speed Straw 400-1800 pcs/min
Materials PLA, PP
Making Size Diameter Φ2-Φ13mm
Length Difference 0.1-1mm
Extruder and Screw Host Diameter 65/33
Vacuum Diameter and Cooling Tank Vacuum Sizing System Not Included
Cooling Tank Length 3.5 m, customizable

Piece output varies with straw length, diameter and wall thickness. The 60–65 kg/h extrusion output is a material throughput range, while the stated pcs/min range reflects different finished straw specifications.

Product Details
